12 ton telescopic boom truck mounted crane

F300TC-04 12-Ton Telescopic Boom Truck-Mounted Crane

Lifting operations are often constrained by the crane’s own weight, which consumes a portion of the vehicle's available payload capacity, as well as by insufficient lifting performance when operating at large radii. For buyers selecting equipment for diverse operational scenarios, balancing load capacity with chassis compatibility can be a significant challenge. The F300TC-04 is a telescopic boom crane designed with a lightweight structure to address these issues. It features a maximum rated lifting capacity of 12,000 kg, a maximum working radius of 15 m, and a lifting moment of 30 ton-meters. It offers 360° continuous rotation while maintaining a low self-weight of 4,130 kg. Equipped with a high-efficiency hydraulic system, it is well-suited for infrastructure, logistics, and municipal lifting projects, effectively balancing operational reach with the vehicle's remaining payload capacity.

Lifting equipment is categorized by specific application: Knuckle boom cranes are ideal for operations in confined spaces; ship-mounted telescopic and knuckle boom cranes are customized for the salt-spray environments found at sea; and grab-equipped cranes—including forestry cranes—are primarily used for handling bulk materials and timber. This telescopic boom crane is designed for long-reach lifting in open areas. It offers optional features such as wireless remote control, load-limiting devices, and hydraulic cooling components to meet the safety and management requirements of various projects.

Product Features

1. Stable Performance Specifications: A maximum lifting capacity of 12,000 kg, a maximum working radius of 15 m, a 30 ton-meter lifting moment, 360° continuous rotation, and a self-weight of 4,130 kg—the lightweight design reduces the load on the chassis.

2. Smooth hydraulic response with optional safety accessories; suitable for municipal, construction, and freight-related lifting tasks.

Tips

1. Once a load-limiting device is installed, it must be calibrated based on actual operating conditions to prevent overloading.

2. For prolonged, continuous operation, it is recommended to install a hydraulic oil cooler to maintain an optimal operating temperature for the hydraulic system.

FAQ

Q1: Can this model be equipped with a grapple to function as a dedicated grab machine or forest crane (log loader)?

A1: The unit features pre-configured attachment points for auxiliary tools, allowing for the installation of basic grappling accessories. However, its operational capacity does not match that of specialized grab machines or forest cranes; for handling large volumes of raw timber or bulk materials, dedicated equipment is recommended.

Q2: What areas should be prioritized during routine maintenance?

A2: Regularly inspect hydraulic line seals, the slewing bearing, and the sliding pads of the telescopic boom. Ensure hydraulic fluid is replaced on schedule, prevent contaminants from entering the hydraulic system, and take measures to avoid leaks or resistance during boom extension and retraction.

Q3: What kind of after-sales support and spare parts availability can be expected?

A3: We provide online technical support and troubleshooting assistance, with a stock of common wear parts readily available. In the event of an on-site malfunction, we can coordinate technical support to minimize downtime.

Q4: How do the application scenarios for this model differ from those of knuckle boom cranes or marine knuckle boom cranes?

A4: This telescopic boom crane is designed for large-radius lifting in open areas. Knuckle boom cranes are better suited for confined spaces with numerous obstacles. Marine-grade telescopic boom cranes undergo specialized anti-corrosion treatment and are designed specifically for maritime and shipboard operations.
